58-degree Tungsten Steel Three-flute End Mill for Aluminum
- Material: Imported tungsten steel
- Number of Blades: 3 Blades
- Spiral angle: 58 °
- Process: unequal helix, unequal segmentation
- Application: Carbide milling cutter, suitable for processing all kinds of high-quality steel, alloy steel, die steel, stainless steel, die steel aluminum alloy, copper alloy, titanium alloy, die steel and other materials.
Specifications of 58-degree Tungsten Steel Three-flute End Mill for Aluminum
| Material | Non-alloy Steel /Alloy Steel Cast Iron | Alloy Steel/ Heat-resistant Steel | Hardened Steel | |||
| Hardness | ~HRC30 | HRC30-HRC45 | HRC45-HRC55 | |||
| Strength | ~1000N/MM2 | 1000-1500N/MM2 | 1500-2000N/MM | |||
| Diameter | Rotational Speed | Feed Rate | Rotational Speed | Feed Rate | Rotational Speed | Feed Rate |
| 3 | 6255 | 180 | 4050 | 135 | 2970 | 90 |
| 4 | 5040 | 220 | 3240 | 150 | 2430 | 95 |
| 5 | 4320 | 225 | 2745 | 190 | 2115 | 110 |
| 6 | 3735 | 225 | 2385 | 190 | 1845 | 110 |
| 8 | 2835 | 240 | 1800 | 190 | 1440 | 110 |
| 10 | 1935 | 240 | 1530 | 190 | 1125 | 110 |
| 12 | 1620 | 190 | 1350 | 170 | 945 | 95 |
| 16 | 1620 | 170 | 990 | 130 | 760 | 80 |
| 20 | 1170 | 120 | 770 | 95 | 560 | 60 |
| Model | Blade Length | Cutting Hardness | Matetial |
Blade Diameter(mm) |
| d1*3c*D4*50L | 3 | HRC55 | Woven Steel | 1 |
| d1.5*4c*D4*50L | 4 | HRC55 | Woven Steel | 1.5 |
| d2*6c*D4*50L | 6 | HRC55 | Tunsgten Steel | 2 |
| d2.5*8c*D4*50L | 8 | HRC55 | Tunsgten Steel | 2.5 |
| d3*8c*D4*50L | 8 | HRC55 | Tunsgten Steel | 3 |
Outstanding Characteristics of 58-degree Tungsten Steel Three-flute End Mill for Aluminum
1. Large chip removal space.
2. Large chip flute, precise R angle, Arc design.
3. Tungsten steel round rod.
4. Large core diameter to enhance rigidity
Superior Design in 58-degree Tungsten Steel Three-flute End Mill for Aluminum
- The ultra-wide chip removal has powerful cutting and discharges chips more smoothly, which can achieve high-speed processing, and the tool is more precise and glossy.
- The circular blade edge cleaning design reduces the wear of the milling cutter during milling and keeps the blade sharper for a longer time. Combined with the 45-degree spiral groove, the chip removal is smooth.
Why Choose KENENG as a Trusted Supplier of 58-degree Tungsten Steel Three-flute End Mill for Aluminum
1. We will use high-precision measuring tools and advanced testing equipment to inspect all parts and processes from incoming materials to final inspection. KENENG ensures that only qualified products are delivered to customers.
2. Benefit from our competitive pricing. Our strong relationships with reliable suppliers allow us to offer competitive quotes promptly.
3. Our dedicated team of engineers provides expert technical support for all your project needs, regardless of order size.
