Specialized Tungsten Steel Milling Cutter for Titanium Alloy

  • Material: Imported tungsten steel
  • Number of Blades: 3 Blades
  • Spiral angle: 68°
  • Process: unequal helix, unequal segmentation
  • Application: Carbide milling cutter, suitable for processing all kinds of high-quality steel, alloy steel, die steel, stainless steel, die steel aluminum alloy, copper alloy, titanium alloy, die steel and other materials.

Are You an OEM Manufacturer?

Yes

Specifications of Specialized Tungsten Steel Milling Cutter for Titanium Alloy

4-Blade Flat Cutter
Specifications 		2-Blade Ball Cutter
Specifications 		4-Blade Round Nose Cutter
Specifications
Blade Diameter(D)*Blade Length(H)*Shank Diameter(D)*Blades(T)*Overall Length(L)
D1*2.5H*D4*4T*50L D1R0.5*1.5H*D4*2T*50L D1R0.2*2H*D4*4T*50L
D1.5*4H*D4*4T*50L D1.5R0.75*2.5H*D4*2T*50L D1.5R0.2*3H*D4*4T*50L
D2*5H*D4*4T*50L D2R1*3H*D4*2T*50L D2R0.2*4H*D4*4T*50L
D2.5*6.5H*D4*4T*50L D3R1.5*4.5H*D3*2T*50L D3R0.2*6H*D3*4T*50L
D3*7.5H*D3*4T*50L D3R1.5*4.5H*D4*2T*50L D3R0.2*6H*D4*4T*50L
D3*7.5H*D4*4T*50L D4R2*6H*D4*2T*50L D3R0.5*6H*D3*4T*50L
D3*7.5H*D4*4T*75L D4R2*6H*D4*2T*75L D3R0.5*6H*D4*4T*50L
D3*7.5H*D4*4T*100L D4R2*6H*D4*2T*100L D4R0.2*8H*D4*4T*50L
D3.5*9H*D4*4T*50L D5R2.5*7.5H*D6*2T*50L D4R0.2*8H*D4*4T*75L
D4*10H*D4*4T*50L D6R3*9H*D6*2T*50L D4R0.2*8H*D4*4T*100L
D4*10H*D4*4T*75L D6R3*9H*D6*2T*75L D4R0.5*8H*D4*4T*50L
D4*10H*D4*4T*100L D6R3*9H*D6*2T*100L D4R0.5*8H*D4*4T*75L
D4*10H*D6*4T*50L D8R4*12H*D8*2T*60L D4R0.5*8H*D4*4T*100L
D4.5*11.25H*D6*4T*50L D8R4*12H*D8*2T*75L D6R0.2*12H*D6*4T*50L
D5*12.5H*D6*4T*50L D8R4*12H*D8*2T*100L D6R0.5*12H*D6*4T*50L
D6*15H*D6*4T*50L D10R5*15H”D10*2T”75L D6R0.5*12H*D6*4T*75L
D6*15H*D6*4T*75L D10R5*15H*D10*2T*100L D6R0.5*12H*D6*4T*100L
D6*15H*D6*4T*100L D10R5*15H*D10*2T*150L D6R1.0*12H*D6*4T*50L
D8*20H*D8*4T*60L D12R6*18H*D12*2T*75L D8R0.5*16H*D8*4T*60L
D8*20H*D8*4T*75L D12R6*18H*D12*2T*100L D8R0.5*16H*D8*4T*75L
D8*20H*D8*4T*100L D12R6*18H*D12*2T*150L D8R0.5*16H*D8*4T*100L
D10*25H*D10*4T*75L D8R1.0*16H*D8*4T*60L
D10*25H*D10*4T*100L D8R1.0*16H*D8*4T*75L
D10*25H*D10*4T*150L D10R0.5*20H*D10*4T*75L
D12*30H*D12*4T*75L D10R0.5*20H*D10*4T*100L

Advantages of Specialized Tungsten Steel Milling Cutter for Titanium Alloy

  1. Monolithic tungsten steel carbide
  2. Unequal screw and unequal edge design
  3. Balzer titanium alloy special coating
  4. Cutting edge passivation treatment. Enhance the rigidity and wear resistance of the tool, effectively extend the service life of the tool.

Superior Design in Specialized Tungsten Steel Milling Cutter for Titanium Alloy

  • Monolithic tungsten steel carbide. Xiamen Golden Egret tungsten steel bar, made of fine tungsten steel and designed and produced with special geometry, is the ideal choice for processing superhard workpieces.
  • Unequal screw and unequal edge design. High seismic efficiency, high wear resistance. Large feed, more wear-resistant, effective suppression of processing vibration.
  • Balzers titanium alloy special coating. Enhance the lubricity and wear resistance of the milling edge, as well as high temperature resistance, so that the tool does not stick to the knife and does not produce the phenomenon of burning. Effectively improve tool life.
  • Cutting edge passivation treatment. Enhance the hardness and wear resistance of the tool, effectively extend the service life of the tool

Why Choose KENENG as a Reliable Supplier of Specialized Tungsten Steel Milling Cutter for Titanium Alloy

1. KENENG use high-precision measuring tools and advanced testing equipment to inspect all parts and processes from incoming materials to final inspection. KENENG ensures that only qualified products are delivered to customers.

2. Competitive pricing: KENENG has stable raw material suppliers who can quickly provide customers with competitive quotes. Mature technology and rich experience in surface strengthening treatment, strong pressure treatment, elimination of internal stress during use, making elasticity more stable.

3. Engineering support: No matter how many parts customers require, KENENG have a professional team of engineers to provide technical support.

Materials we can use on Specialized Tungsten Steel Milling Cutter for Titanium Alloy
